Grupo de funções · sistema de demonstração sintéticoTécnico

ZSD_ORDER

O catálogo de exemplo abaixo é exibido em inglês, tal como foi gerado.

Generated from the code structure only: what the code does and where, each line citing its evidence. It does not describe business purpose. See How to read this catalogue for how to read the tags.

Como cada citação é verificada

Como ler esta página. Cada linha indica o que o código e a configuração fazem, e onde, seguida da sua evidência: CODE é a linha exata do código-fonte (numerada como na SE80), GRAPH uma relação registrada, SCHEMA uma definição do Dicionário ABAP, EXPORT um registro de um arquivo exportado (a configuração, o índice da lista de utilização do SAP, a lista de transações ou de jobs, ou o inventário de objetos e pacotes) e INFERRED uma dedução que não é evidência. Clique em uma tag CODE ou EXPORT para abrir a evidência.

Como ler as tags

93 tags de citação nesta página (41 CODE, 36 GRAPH, 4 SCHEMA, 10 EXPORT, 2 INFERRED). 91 passaram na verificação do auditor de citações; 2 são marcadores INFERRED, que não são evidência e não são verificados.

Onde este objeto se situa na rota da ordem de venda.

Cinco das seis fases rodam em módulos de função de ZSD_ORDER. Cada fase destacada leva à sua linha, mais abaixo nesta página.

A ordem chegaZSD_ORDER_IDOC_INLinha 34 de LZSD_ORDERU03
Verificação de créditoZSD_ORDER_CREATE, ZSD_ORDER_CHECK_CREDITLinha 18 de LZSD_ORDERU01
Ordem criadaZSD_ORDER_CREATELinha 33 de LZSD_ORDERU01
Canal e status registradosZSD_ORDER_CREATELinha 55 de LZSD_ORDERU01
Etiqueta de picking impressaNão está nesta página
Status atualizadoZSD_ORDER_STATUS_UPDATELinha 8 de LZSD_ORDERU04

Os nomes das fases e a ordem delas foram acrescentados para esta página. O catálogo abaixo é exibido tal como foi gerado. A fase 5 roda no programa ZWM_PICK_LABEL, fora deste grupo de funções.

Type: function group
Package: ZSD_DM_ORDERS — Sales order extensions, application component SD, in package ZDEMO EXPORT:cg_objects.tsv:3checked EXPORT:cg_packages.tsv:4checked
Description: Sales order services
Function modules: 4 · include files: 11 · lines of code: 213

Files

Files
Include	Role	Lines
`SAPLZSD_ORDER`	main program	12
`LZSD_ORDERF01`	subroutines (FORM)	16
`LZSD_ORDERI01`	PAI modules	13
`LZSD_ORDERO01`	PBO modules	4
`LZSD_ORDERTOP`	global data (TOP)	6
`LZSD_ORDERU01`	function module	57
`LZSD_ORDERU02`	function module	33
`LZSD_ORDERU03`	function module	50
`LZSD_ORDERU04`	function module	14
`LZSD_ORDERUXX`	function module list (UXX)	4
`SAPLZSD_ORDER-0100`	screen flow logic	4

Function modules

Function modules
Function module	Defined at	Interface (from the generated interface comment)	Short text
`ZSD_ORDER_CREATE`	`LZSD_ORDERU01` CODE:lzsd_orderu01.abap:1checked	IMPORTING: IS_HEADER type BAPISDHD1, IT_ITEMS type ZSD_T_ORDER_ITEMS, IV_KUNNR type KUNNR, IV_AMOUNT type NETWR_AK, IV_CHANNEL type ZSD_CHANNEL; EXPORTING: EV_VBELN type VBELN_VA, ET_RETURN type BAPIRET2_T	Create a sales order from staged data
`ZSD_ORDER_CHECK_CREDIT`	`LZSD_ORDERU02` CODE:lzsd_orderu02.abap:1checked	IMPORTING: IV_KUNNR type KUNNR, IV_AMOUNT type NETWR_AK; EXCEPTIONS: CREDIT_BLOCK	Check the customer credit limit
`ZSD_ORDER_IDOC_IN` (IDoc inbound signature INFERRED:has IDOC_CONTRL/IDOC_DATA parameters)	`LZSD_ORDERU03` CODE:lzsd_orderu03.abap:1checked	IMPORTING: INPUT_METHOD like BDWFAP_PAR-INPUTMETHD, MASS_PROCESSING like BDWFAP_PAR-MASS_PROC; EXPORTING: WORKFLOW_RESULT like BDWF_PARAM-RESULT; TABLES: IDOC_CONTRL structure EDIDC, IDOC_DATA structure EDIDD, IDOC_STATUS structure BDIDOCSTAT	Inbound IDoc ORDERS: create a sales order
`ZSD_ORDER_STATUS_UPDATE` (called in update task)	`LZSD_ORDERU04` CODE:lzsd_orderu04.abap:1checked	IMPORTING: IV_VBELN type VBELN_VA, IV_STATUS type ZSD_ORDER_STATUS	Update the order status (update task)

Program structure

LZSD_ORDERUXX includes LZSD_ORDERU01 GRAPH:INCLUDESchecked CODE:lzsd_orderuxx.abap:1checked
LZSD_ORDERUXX includes LZSD_ORDERU02 GRAPH:INCLUDESchecked CODE:lzsd_orderuxx.abap:2checked
LZSD_ORDERUXX includes LZSD_ORDERU03 GRAPH:INCLUDESchecked CODE:lzsd_orderuxx.abap:3checked
LZSD_ORDERUXX includes LZSD_ORDERU04 GRAPH:INCLUDESchecked CODE:lzsd_orderuxx.abap:4checked
SAPLZSD_ORDER includes LZSD_ORDERTOP GRAPH:INCLUDESchecked CODE:saplzsd_order.abap:4checked
SAPLZSD_ORDER includes LZSD_ORDERUXX GRAPH:INCLUDESchecked CODE:saplzsd_order.abap:5checked
SAPLZSD_ORDER includes LZSD_ORDERF01 GRAPH:INCLUDESchecked CODE:saplzsd_order.abap:10checked
SAPLZSD_ORDER includes LZSD_ORDERO01 GRAPH:INCLUDESchecked CODE:saplzsd_order.abap:11checked
SAPLZSD_ORDER includes LZSD_ORDERI01 GRAPH:INCLUDESchecked CODE:saplzsd_order.abap:12checked

Subroutines (FORM)

ADD_RETURN defined in LZSD_ORDERF01 CODE:lzsd_orderf01.abap:13checked
LOG_EVENT defined in LZSD_ORDERF01 CODE:lzsd_orderf01.abap:4checked

Dialog modules (MODULE)

STATUS_0100 defined in LZSD_ORDERO01 CODE:lzsd_ordero01.abap:1checked (PBO)
USER_COMMAND_0100 defined in LZSD_ORDERI01 CODE:lzsd_orderi01.abap:1checked (PAI)

Screens

Screen 0100 of `SAPLZSD_ORDER`

Fields (from the exported screen definition): ZSD_ORDER_LOG-VBELN, ZSD_ORDER_LOG-CHANNEL, ZSD_ORDER_LOG-STATUS, GV_OKCODE
First screen of transaction ZSD_STATUS EXPORT:cg_transactions.tsv:3checked
PBO: SAPLZSD_ORDER-0100 calls LZSD_ORDERO01 GRAPH:CALLSchecked CODE:saplzsd_order-0100.abap:2checked — module STATUS_0100
PAI: SAPLZSD_ORDER-0100 calls LZSD_ORDERI01 GRAPH:CALLSchecked CODE:saplzsd_order-0100.abap:4checked — module USER_COMMAND_0100

How it is started

Transaction ZSD_STATUS starts SAPLZSD_ORDER GRAPH:STARTSchecked EXPORT:cg_transactions.tsv:3checked — screen 0100, text: Maintain order status
Message type ORDERS is processed by ZSD_ORDER_IDOC_IN GRAPH:PROCESSED_BYchecked EXPORT:cg_cfg_edifct.tsv:2checked — IDoc type ORDERS05, inbound
Process code ZORD runs the function module registered for message type ORDERS: ZSD_ORDER_IDOC_IN GRAPH:PROCESSED_BYchecked EXPORT:cg_cfg_tbd52.tsv:2checked EXPORT:cg_cfg_edifct.tsv:2checked — inbound, partner profiles (cg_cfg_edp21.tsv) are not in the export INFERRED:message type from the function module's registration, not from a partner profile

Database access

VBAK — Sales document header
- LZSD_ORDERU02 reads VBAK GRAPH:READSchecked SCHEMA:DDIC:VBAKchecked CODE:lzsd_orderu02.abap:26checked — in function ZSD_ORDER_CHECK_CREDIT
ZFI_I_OPENITEMS — CDS view of the export
- LZSD_ORDERU02 reads ZFI_I_OPENITEMS GRAPH:READSchecked CODE:lzsd_orderu02.abap:23checked — CDS view, in function ZSD_ORDER_CHECK_CREDIT
ZSD_CREDIT_LIM — Customer credit limits
- LZSD_ORDERU02 reads ZSD_CREDIT_LIM GRAPH:READSchecked SCHEMA:DDIC:ZSD_CREDIT_LIMchecked CODE:lzsd_orderu02.abap:14checked — in function ZSD_ORDER_CHECK_CREDIT
ZSD_ORDER_LOG — Sales order channel and status log
- LZSD_ORDERU01 inserts into ZSD_ORDER_LOG GRAPH:CREATESchecked SCHEMA:DDIC:ZSD_ORDER_LOGchecked CODE:lzsd_orderu01.abap:55checked — in function ZSD_ORDER_CREATE
- LZSD_ORDERU04 updates ZSD_ORDER_LOG GRAPH:WRITESchecked SCHEMA:DDIC:ZSD_ORDER_LOGchecked CODE:lzsd_orderu04.abap:8checked — in function ZSD_ORDER_STATUS_UPDATE

Calls to other code

Custom code

LZSD_ORDERF01 calls ZCA_LOG_WRITE GRAPH:CALLSchecked CODE:lzsd_orderf01.abap:6checked — in form LOG_EVENT (in ZCA_TOOLS)
LZSD_ORDERU01 calls ZSD_ORDER_CHECK_CREDIT GRAPH:CALLSchecked CODE:lzsd_orderu01.abap:18checked — in function ZSD_ORDER_CREATE (in ZSD_ORDER)
LZSD_ORDERU03 calls ZSD_ORDER_CREATE GRAPH:CALLSchecked CODE:lzsd_orderu03.abap:34checked — in function ZSD_ORDER_IDOC_IN (in ZSD_ORDER)
LZSD_ORDERI01 calls ZSD_ORDER_STATUS_UPDATE GRAPH:CALLSchecked CODE:lzsd_orderi01.abap:4checked — in update task, in module USER_COMMAND_0100 (in ZSD_ORDER)

SAP and other objects outside the export

LZSD_ORDERU01 calls BAPI_SALESORDER_CREATEFROMDAT2 GRAPH:CALLSchecked CODE:lzsd_orderu01.abap:33checked — in function ZSD_ORDER_CREATE, recorded in the SAP where-used index EXPORT:cg_xref_cross.tsv:2checked
LZSD_ORDERU01 calls BAPI_TRANSACTION_COMMIT GRAPH:CALLSchecked CODE:lzsd_orderu01.abap:47checked — in function ZSD_ORDER_CREATE, recorded in the SAP where-used index EXPORT:cg_xref_cross.tsv:4checked
LZSD_ORDERU01 calls BAPI_TRANSACTION_ROLLBACK GRAPH:CALLSchecked CODE:lzsd_orderu01.abap:44checked — in function ZSD_ORDER_CREATE, recorded in the SAP where-used index EXPORT:cg_xref_cross.tsv:3checked

Called from other custom code

LZSD_ORDERI01 calls ZSD_ORDER_STATUS_UPDATE GRAPH:CALLSchecked CODE:lzsd_orderi01.abap:4checked — in update task, in module USER_COMMAND_0100 (from ZSD_ORDER)
LZSD_ORDERU01 calls ZSD_ORDER_CHECK_CREDIT GRAPH:CALLSchecked CODE:lzsd_orderu01.abap:18checked — in function ZSD_ORDER_CREATE (from ZSD_ORDER)
LZSD_ORDERU03 calls ZSD_ORDER_CREATE GRAPH:CALLSchecked CODE:lzsd_orderu03.abap:34checked — in function ZSD_ORDER_IDOC_IN (from ZSD_ORDER)
MV45AFZZ calls ZSD_ORDER_STATUS_UPDATE GRAPH:CALLSchecked CODE:mv45afzz.abap:18checked — in update task, in form USEREXIT_SAVE_DOCUMENT (from MV45AFZZ)
ZWM_PICK_LABEL calls ZSD_ORDER_STATUS_UPDATE GRAPH:CALLSchecked CODE:zwm_pick_label.abap:40checked — in update task (from ZWM_PICK_LABEL)

Messages, memory and other resources

LZSD_ORDERI01 raises a message of class ZSD_MSG GRAPH:USES_MESSAGEchecked CODE:lzsd_orderi01.abap:9checked — in module USER_COMMAND_0100 (number 013, type S) (see message class ZSD_MSG)
LZSD_ORDERU01 raises a message of class ZSD_MSG GRAPH:USES_MESSAGEchecked CODE:lzsd_orderu01.abap:26checked — in function ZSD_ORDER_CREATE (number 010, type E) (see message class ZSD_MSG)
LZSD_ORDERU02 raises a message of class ZSD_MSG GRAPH:USES_MESSAGEchecked CODE:lzsd_orderu02.abap:20checked — in function ZSD_ORDER_CHECK_CREDIT (number 014, type W) (see message class ZSD_MSG)
LZSD_ORDERU02 raises a message of class ZSD_MSG GRAPH:USES_MESSAGEchecked CODE:lzsd_orderu02.abap:31checked — in function ZSD_ORDER_CHECK_CREDIT (number 011, type W) (see message class ZSD_MSG)
LZSD_ORDERU04 raises a message of class ZSD_MSG GRAPH:USES_MESSAGEchecked CODE:lzsd_orderu04.abap:12checked — in function ZSD_ORDER_STATUS_UPDATE (number 012, type A) (see message class ZSD_MSG)

How to read this catalogue

Every factual line carries citation tags, re-checked by a script after generation:
- [CODE:<include>.abap:<line>]: the statement at that line of that include (the same line number as in SE80/SE37).
- [GRAPH:<TYPE>]: an edge of that type exists in the code graph between the two names just before it.
- [SCHEMA:DDIC:<TABLE>]: the table (and any TABLE-FIELD named) exists in the exported ABAP Dictionary.
- [SCHEMA:DTEL:<name>], [SCHEMA:DOMA:<name>], [SCHEMA:TTYP:<name>], [SCHEMA:MSAG:<class>]: the data element, domain, table type or message class exists in the export; [SCHEMA:DOMA:<name>=<value>] (or [SCHEMA:DOMA:<name>#<n>], the n-th value) names one of the domain's fixed values, [SCHEMA:MSAG:<class>-<nnn>] one of the class's messages, each shown in the text just before the tag.
- [SCHEMA:<kind>:<object>.<PROPERTY>=<value>]: a relation or setting of a dictionary object as the export records it, for example [SCHEMA:DDIC:<append>.APPENDS_TO=<table>], [SCHEMA:DDIC:<table>-<field>.DATA_ELEMENT=<name>], [SCHEMA:DTEL:<name>.DOMAIN=<domain>] or [SCHEMA:DDIC:<table>.DELIVERY_CLASS=<class>]; the value is shown in the text just before the tag.
- [EXPORT:<file>.tsv:<line>]: that row of an exported side file (transactions, jobs, SAP where-used index, configuration tables, modification log); line 1 is the column header, so data rows start at line 2. Every name in the sentence's code spans is in the cited row(s).
- [INFERRED:<reason>]: a deduction or a limit, not evidence.
A passing citation proves the evidence exists, not that a business interpretation is right.
Nothing here describes business purpose; that needs a subject-matter expert.

Linhas de código citadas

Cada arquivo-fonte citado por uma tag CODE desta página, completo e exatamente como foi exportado. Os números de linha são os do editor ABAP; as linhas citadas são marcadas com um ponto. Cada tag CODE leva à sua linha.

`LZSD_ORDERU01`

57 linhas · linhas citadas: 1, 18, 26, 33, 44, 47, 55

1FUNCTION zsd_order_create.2*"----------------------------------------------------------------------3*"*"Local Interface:4*"  IMPORTING5*"     VALUE(IS_HEADER) TYPE  BAPISDHD16*"     VALUE(IT_ITEMS) TYPE  ZSD_T_ORDER_ITEMS7*"     VALUE(IV_KUNNR) TYPE  KUNNR8*"     VALUE(IV_AMOUNT) TYPE  NETWR_AK9*"     VALUE(IV_CHANNEL) TYPE  ZSD_CHANNEL10*"  EXPORTING11*"     VALUE(EV_VBELN) TYPE  VBELN_VA12*"     VALUE(ET_RETURN) TYPE  BAPIRET2_T13*"----------------------------------------------------------------------14  DATA lt_items TYPE STANDARD TABLE OF bapisditm.15  DATA lt_partners TYPE STANDARD TABLE OF bapiparnr.16  DATA ls_log TYPE zsd_order_log.17 18  CALL FUNCTION 'ZSD_ORDER_CHECK_CREDIT'19    EXPORTING20      iv_kunnr     = iv_kunnr21      iv_amount    = iv_amount22    EXCEPTIONS23      credit_block = 124      OTHERS       = 2.25  IF sy-subrc <> 0.26    MESSAGE e010(zsd_msg) WITH iv_kunnr INTO DATA(lv_msg).27    PERFORM add_return USING lv_msg CHANGING et_return.28    RETURN.29  ENDIF.30 31  lt_items = CORRESPONDING #( it_items ).32  APPEND VALUE #( partn_role = 'AG' partn_numb = iv_kunnr ) TO lt_partners.33  CALL FUNCTION 'BAPI_SALESORDER_CREATEFROMDAT2'34    EXPORTING35      order_header_in = is_header36    IMPORTING37      salesdocument   = ev_vbeln38    TABLES39      return          = et_return40      order_items_in  = lt_items41      order_partners  = lt_partners.42 43  IF ev_vbeln IS INITIAL.44    CALL FUNCTION 'BAPI_TRANSACTION_ROLLBACK'.45    RETURN.46  ENDIF.47  CALL FUNCTION 'BAPI_TRANSACTION_COMMIT'48    EXPORTING49      wait = abap_true.50 51  ls_log-vbeln   = ev_vbeln.52  ls_log-channel = iv_channel.53  ls_log-status  = 'C'.54  ls_log-erdat   = sy-datum.55  INSERT zsd_order_log FROM ls_log.56  PERFORM log_event USING ev_vbeln 'Order created'.57ENDFUNCTION.

`LZSD_ORDERU02`

33 linhas · linhas citadas: 1, 14, 20, 23, 26, 31

1FUNCTION zsd_order_check_credit.2*"----------------------------------------------------------------------3*"*"Local Interface:4*"  IMPORTING5*"     VALUE(IV_KUNNR) TYPE  KUNNR6*"     VALUE(IV_AMOUNT) TYPE  NETWR_AK7*"  EXCEPTIONS8*"      CREDIT_BLOCK9*"----------------------------------------------------------------------10  DATA ls_limit TYPE zsd_credit_lim.11  DATA lv_open TYPE netwr_ak.12  DATA lv_overdue TYPE dmbtr.13 14  SELECT SINGLE * FROM zsd_credit_lim INTO ls_limit15    WHERE kunnr = iv_kunnr.16  IF sy-subrc <> 0.17    RETURN.18  ENDIF.19  IF ls_limit-blocked = abap_true.20    MESSAGE w014(zsd_msg) WITH iv_kunnr RAISING credit_block.21  ENDIF.22 23  SELECT SUM( dmbtr ) FROM zfi_i_openitems INTO @lv_overdue24    WHERE kunnr = @iv_kunnr.25 26  SELECT SUM( netwr ) FROM vbak INTO lv_open27    WHERE kunnr = iv_kunnr28      AND gbstk <> 'C'.29 30  IF lv_open + lv_overdue + iv_amount > ls_limit-credit_limit.31    MESSAGE w011(zsd_msg) WITH iv_kunnr RAISING credit_block.32  ENDIF.33ENDFUNCTION.

`LZSD_ORDERU03`

50 linhas · linhas citadas: 1, 34

1FUNCTION zsd_order_idoc_in.2*"----------------------------------------------------------------------3*"*"Local Interface:4*"  IMPORTING5*"     VALUE(INPUT_METHOD) LIKE  BDWFAP_PAR-INPUTMETHD6*"     VALUE(MASS_PROCESSING) LIKE  BDWFAP_PAR-MASS_PROC7*"  EXPORTING8*"     VALUE(WORKFLOW_RESULT) LIKE  BDWF_PARAM-RESULT9*"  TABLES10*"      IDOC_CONTRL STRUCTURE  EDIDC11*"      IDOC_DATA STRUCTURE  EDIDD12*"      IDOC_STATUS STRUCTURE  BDIDOCSTAT13*"----------------------------------------------------------------------14  DATA ls_header TYPE bapisdhd1.15  DATA lt_items TYPE zsd_t_order_items.16  DATA lv_vbeln TYPE vbeln_va.17  DATA lv_kunnr TYPE kunnr.18  DATA lt_return TYPE bapiret2_t.19  DATA ls_e1edk01 TYPE e1edk01.20  DATA ls_e1edka1 TYPE e1edka1.21 22  LOOP AT idoc_data WHERE segnam = 'E1EDK01'.23    ls_e1edk01 = idoc_data-sdata.24    ls_header-doc_type = 'ZOR'.25    ls_header-currency = ls_e1edk01-curcy.26  ENDLOOP.27  LOOP AT idoc_data WHERE segnam = 'E1EDKA1'.28    ls_e1edka1 = idoc_data-sdata.29    IF ls_e1edka1-parvw = 'AG'.30      lv_kunnr = ls_e1edka1-partn.31    ENDIF.32  ENDLOOP.33 34  CALL FUNCTION 'ZSD_ORDER_CREATE'35    EXPORTING36      is_header  = ls_header37      it_items   = lt_items38      iv_kunnr   = lv_kunnr39      iv_amount  = 040      iv_channel = 'EDI'41    IMPORTING42      ev_vbeln   = lv_vbeln43      et_return  = lt_return.44 45  LOOP AT idoc_contrl.46    idoc_status-docnum = idoc_contrl-docnum.47    idoc_status-status = COND #( WHEN lv_vbeln IS INITIAL THEN '51' ELSE '53' ).48    APPEND idoc_status.49  ENDLOOP.50ENDFUNCTION.

`LZSD_ORDERU04`

14 linhas · linhas citadas: 1, 8, 12

1FUNCTION zsd_order_status_update.2*"----------------------------------------------------------------------3*"*"Local Interface:4*"  IMPORTING5*"     VALUE(IV_VBELN) TYPE  VBELN_VA6*"     VALUE(IV_STATUS) TYPE  ZSD_ORDER_STATUS7*"----------------------------------------------------------------------8  UPDATE zsd_order_log SET status = iv_status9                           aedat = sy-datum10    WHERE vbeln = iv_vbeln.11  IF sy-subrc <> 0.12    MESSAGE a012(zsd_msg) WITH iv_vbeln.13  ENDIF.14ENDFUNCTION.

`LZSD_ORDERUXX`

4 linhas · linhas citadas: 1, 2, 3, 4

1  INCLUDE lzsd_orderu01.2  INCLUDE lzsd_orderu02.3  INCLUDE lzsd_orderu03.4  INCLUDE lzsd_orderu04.

`SAPLZSD_ORDER`

12 linhas · linhas citadas: 4, 5, 10, 11, 12

1*******************************************************************2*   System-defined Include-files.                                 *3*******************************************************************4  INCLUDE lzsd_ordertop.                       " Global Data5  INCLUDE lzsd_orderuxx.                       " Function Modules6 7*******************************************************************8*   User-defined Include-files (if necessary).                    *9*******************************************************************10  INCLUDE lzsd_orderf01.                       " Subroutines11  INCLUDE lzsd_ordero01.                       " PBO-Modules12  INCLUDE lzsd_orderi01.                       " PAI-Modules

`LZSD_ORDERF01`

16 linhas · linhas citadas: 4, 6, 13

1*----------------------------------------------------------------------*2* Form routines of ZSD_ORDER3*----------------------------------------------------------------------*4FORM log_event USING pv_vbeln TYPE vbeln_va5                     pv_text TYPE csequence.6  CALL FUNCTION 'ZCA_LOG_WRITE'7    EXPORTING8      iv_object    = gc_log_object9      iv_subobject = 'ORDER'10      iv_text      = |{ pv_vbeln }: { pv_text }|.11ENDFORM.12 13FORM add_return USING pv_msg TYPE string14                CHANGING ct_return TYPE bapiret2_t.15  APPEND VALUE #( type = 'E' id = 'ZSD_MSG' number = '010' message = pv_msg ) TO ct_return.16ENDFORM.

`LZSD_ORDERO01`

4 linhas · linhas citadas: 1

1MODULE status_0100 OUTPUT.2  SET PF-STATUS 'MAIN'.3  SET TITLEBAR 'T100'.4ENDMODULE.

`LZSD_ORDERI01`

13 linhas · linhas citadas: 1, 4, 9

1MODULE user_command_0100 INPUT.2  CASE gv_okcode.3    WHEN 'SAVE'.4      CALL FUNCTION 'ZSD_ORDER_STATUS_UPDATE' IN UPDATE TASK5        EXPORTING6          iv_vbeln  = zsd_order_log-vbeln7          iv_status = zsd_order_log-status.8      COMMIT WORK.9      MESSAGE s013(zsd_msg) WITH zsd_order_log-vbeln.10    WHEN 'BACK' OR 'EXIT'.11      LEAVE TO SCREEN 0.12  ENDCASE.13ENDMODULE.

`SAPLZSD_ORDER-0100`

4 linhas · linhas citadas: 2, 4

1PROCESS BEFORE OUTPUT.2  MODULE status_0100.3PROCESS AFTER INPUT.4  MODULE user_command_0100.

`MV45AFZZ`

22 linhas · linhas citadas: 18

MV45AFZZ é o nome de um include de user exit do SAP; aqui, o código que ele contém é código fictício do próprio sistema de demonstração.

1*---------------------------------------------------------------------*2*       FORM USEREXIT_MOVE_FIELD_TO_VBAK                              *3*---------------------------------------------------------------------*4*       Sales channel default for web orders                         *5*---------------------------------------------------------------------*6FORM userexit_move_field_to_vbak.7  IF vbak-auart = 'ZOR' AND vbak-zz_channel IS INITIAL.8    vbak-zz_channel = 'WEB'.9  ENDIF.10ENDFORM.11 12*---------------------------------------------------------------------*13*       FORM USEREXIT_SAVE_DOCUMENT                                   *14*---------------------------------------------------------------------*15*       Order status log, written in the update task                 *16*---------------------------------------------------------------------*17FORM userexit_save_document.18  CALL FUNCTION 'ZSD_ORDER_STATUS_UPDATE' IN UPDATE TASK19    EXPORTING20      iv_vbeln  = vbak-vbeln21      iv_status = 'S'.22ENDFORM.

`ZWM_PICK_LABEL`

49 linhas · linhas citadas: 40

1REPORT zwm_pick_label.2 3PARAMETERS p_vbeln TYPE vbeln_vl OBLIGATORY.4PARAMETERS p_form TYPE tdsfname DEFAULT 'ZWM_PICK_LABEL'.5 6DATA gt_items TYPE STANDARD TABLE OF lips.7DATA gv_fm TYPE rs38l_fnam.8DATA gs_log TYPE zwm_label_log.9DATA gv_channel TYPE zsd_channel.10DATA gv_vbeln_so TYPE vbeln_va.11 12START-OF-SELECTION.13  SELECT * FROM lips INTO TABLE @gt_items14    WHERE vbeln = @p_vbeln.15  IF sy-subrc <> 0.16    MESSAGE e001(zwm_msg) WITH p_vbeln.17  ENDIF.18 19  SELECT SINGLE vbeln_so FROM zsd_dlv_queue20    WHERE vbeln = @p_vbeln21    INTO @gv_vbeln_so.22  SELECT SINGLE channel FROM zsd_order_log23    WHERE vbeln = @gv_vbeln_so24    INTO @gv_channel.25 26  CALL FUNCTION 'SSF_FUNCTION_MODULE_NAME'27    EXPORTING28      formname = p_form29    IMPORTING30      fm_name  = gv_fm.31 32  CALL FUNCTION gv_fm33    EXPORTING34      iv_vbeln   = p_vbeln35      iv_channel = gv_channel36    TABLES37      it_items   = gt_items.38 39  UPDATE zsd_dlv_queue SET label_printed = abap_true WHERE vbeln = p_vbeln.40  CALL FUNCTION 'ZSD_ORDER_STATUS_UPDATE' IN UPDATE TASK41    EXPORTING42      iv_vbeln  = gv_vbeln_so43      iv_status = 'L'.44  COMMIT WORK.45 46  gs_log-vbeln      = p_vbeln.47  gs_log-printed_on = sy-datum.48  gs_log-printed_at = sy-uzeit.49  INSERT zwm_label_log FROM gs_log.

Registros exportados citados

Cada registro exportado citado por uma tag EXPORT desta página. A linha 1 de cada arquivo exportado é o cabeçalho das colunas, por isso os registros de dados começam na linha 2.

cg_objects.tsv, linha 3
Coluna	Valor
object	FUGR
name	ZSD_ORDER
package	ZSD_DM_ORDERS
generated	vazio
source_system	DEM
master_language	E

cg_packages.tsv, linha 4
Coluna	Valor
package	ZSD_DM_ORDERS
parent	ZDEMO
software_component	HOME
application_component	SD
text	Sales order extensions

cg_transactions.tsv, linha 3
Coluna	Valor
tcode	ZSD_STATUS
program	SAPLZSD_ORDER
screen	0100
parameters	vazio
text	Maintain order status

cg_cfg_edifct.tsv, linha 2
Coluna	Valor
FCTNAM	ZSD_ORDER_IDOC_IN
FCTVRS	vazio
IDOCTYP	ORDERS05
CIMTYP	vazio
MESTYP	ORDERS
MESCOD	vazio
MESFCT	vazio
OBJNAM	vazio
DIRECT	2

cg_cfg_tbd52.tsv, linha 2
Coluna	Valor
MANDT	800
EVCODE	ZORD
FUNCNAME	ZSD_ORDER_IDOC_IN

cg_xref_cross.tsv, linha 2
Coluna	Valor
direction	from_custom
type	F
name	BAPI_SALESORDER_CREATEFROMDAT2
include	LZSD_ORDERU01

cg_xref_cross.tsv, linha 4
Coluna	Valor
direction	from_custom
type	F
name	BAPI_TRANSACTION_COMMIT
include	LZSD_ORDERU01

cg_xref_cross.tsv, linha 3
Coluna	Valor
direction	from_custom
type	F
name	BAPI_TRANSACTION_ROLLBACK
include	LZSD_ORDERU01

Cada linha factual traz uma citação. Uma citação verificada prova que a evidência existe; não prova uma interpretação de negócio.
